FLIR i64 Wärmebildkamera · 480 × 640 Pixel · 7.5–13 µm

<table class="ds-table"><caption>Imaging &amp; Optik</caption><tbody><tr><th>IR-Auflösung</th><td>480 × 640 Pixel</td></tr><tr><th>NETD</th><td>&lt;40 mK at 30°C (86°F)</td></tr><tr><th>Sichtfeld</th><td>37° × 49°</td></tr><tr><th>Mindestfokusabstand</th><td>0.5 m</td></tr><tr><th>Räumliche Auflösung (IFOV)</th><td>1.4 mrad</td></tr><tr><th>Blendenzahl (F#)</th><td>1.4</td></tr><tr><th>Bildfrequenz</th><td>30 Hz</td></tr><tr><th>Fokus</th><td>Fixed focus</td></tr><tr><th>Detektor-Typ</th><td>Focal plane array (FPA), uncooled microbolometer</td></tr><tr><th>Spektralbereich</th><td>7.5–13 µm</td></tr></tbody></table>

<table class="ds-table"><caption>Messung</caption><tbody><tr><th>Kameratemperaturbereich</th><td>–20 to 200°C (–4 to 392°F) 10 to 550°C (50 to 1022°F)</td></tr><tr><th>Messbereich und Genauigkeit</th><td>Range –20 to 200°C (–4 to 392°F): 0 to 100°C (32 to 212°F): ±2°C (±3.6°F) 100 to 200°C (212 to 392°F): ±2% Range 10 to 550°C (50 to 1022°F): 10 to 100°C (50 to 212°F): ±2°C (±7.2°F) 100 to 550°C (212 to 1022°F): ±2%</td></tr><tr><th>Spotmessung</th><td>Center spot, box with min./max.</td></tr><tr><th>Isotherme</th><td>Above, Below</td></tr><tr><th>Delta T</th><td>Ja, NFPA 70B compliant</td></tr><tr><th>Emissionsgrad-Korrektur</th><td>Variable from 0.1 to 1.0</td></tr><tr><th>Emissionsgrad-Tabelle</th><td>Emissivity table of predefined materials</td></tr><tr><th>Messkorrekturen</th><td>Emissivity, matt/semi-matt/semi-gloss + custom value, reflected apparent temperature, atmospheric compensation</td></tr><tr><th>Farbpaletten</th><td>Iron, White hot, Black hot, Rainbow, Arctic, Lava, Rainbow HC</td></tr><tr><th>Einstelloptionen</th><td>Local adaptation of units, language, date and time formats</td></tr></tbody></table>

<table class="ds-table"><caption>Display &amp; Bedienung</caption><tbody><tr><th>Display</th><td>5 in. 720 × 1280 color LCD</td></tr><tr><th>Touchscreen</th><td>Capacitive touch</td></tr><tr><th>Text</th><td>Text annotation on image using onscreen keyboard</td></tr><tr><th>LED-Leuchte</th><td>Manually activated bright LED</td></tr><tr><th>Bildanpassung</th><td>Automatic/Manual</td></tr><tr><th>Bildmodi</th><td>Thermal MSX, Thermal, Picture-in-Picture, Digital camera.</td></tr><tr><th>Multi Spectral Dynamic Imaging (MSX)</th><td>IR image enhanced with visible camera detail</td></tr><tr><th>Bild-in-Bild</th><td>IR area on visual image</td></tr></tbody></table>

<table class="ds-table"><caption>Visuelle Kamera</caption><tbody><tr><th>Digitalkamera-Auflösung</th><td>8 MP</td></tr><tr><th>Digitalkamera-Sichtfeld</th><td>50.5° × 64.5°</td></tr><tr><th>Autofokus</th><td>Ja</td></tr><tr><th>Laser</th><td>Class 2, 0.05–40 m (1.6–131 ft.)</td></tr><tr><th>Laser-Ausrichtung</th><td>Position is automatically displayed on the infrared image</td></tr></tbody></table>

<table class="ds-table"><caption>Schnittstellen &amp; Speicherung</caption><tbody><tr><th>Schnittstellen</th><td>USB-C: Data transfer to and from PC and Mac device Display port over USB-C</td></tr><tr><th>WLAN</th><td>IEEE 802.11 a/ac/b/g/n (2.4 and 5 GHz) Infrastructure (STA)</td></tr><tr><th>Bluetooth</th><td>Bluetooth 5.0</td></tr><tr><th>Cybersicherheit</th><td>EN18031-1 EN18031-2</td></tr><tr><th>Betriebsfrequenz</th><td>WLAN 2.4 GHz: 2412–2462 MHz WLAN 5 GHz: 5150-5250 MHz Note that frequency band 5150-5250 MHz is for indoor use only, see national regulations (e.g. Japan and Canada)</td></tr><tr><th>Dateiformat</th><td>Standard JPEG, 14-bit measurement data included</td></tr><tr><th>Speichermedien</th><td>Internal memory and onboard FLIR Ignite cloud connectivity (with Wi-Fi)</td></tr></tbody></table>

<table class="ds-table"><caption>Umwelt &amp; Normen</caption><tbody><tr><th>Betriebstemperatur</th><td>–15°C to +50°C (+5°F to +122°F)</td></tr><tr><th>Lagertemperatur</th><td>–40°C to +70°C (–40°F to +158°F)</td></tr><tr><th>Luftfeuchte</th><td>IEC 60068-2-30/24 h 95% relative humidity</td></tr><tr><th>EMC</th><td>EN 301 489-1 RED EN 301 489-17 EN 301 489-19 EN 55032 Class B (Emission) EN 55035 (Immunity) EN 61000-6-2 Immunity according to Industrial FCC 47 CFR part 15 B, class B (Emission) ICES-003</td></tr><tr><th>Funkspektrum</th><td>ETSI EN 300 328 ETSI EN 301 893 FCC 47 CFR part 15 RSS-247</td></tr><tr><th>Gefahrstoff-Richtlinien</th><td>WEEE 2012/19/EU RoHs 2011/65/EU</td></tr><tr><th>Stoßfestigkeit</th><td>25 g (IEC 60068-2-27)</td></tr><tr><th>Vibration</th><td>2 g (IEC 60068-2-6)</td></tr><tr><th>Sicherheits-Normen</th><td>Camera: IEC/EN 62368-1 Power supply: IEC/EN 62368-1 UL/J/(AS/NZS) 62368-1 GB 4943</td></tr></tbody></table>

<table class="ds-table"><caption>Mechanik &amp; Stromversorgung</caption><tbody><tr><th>Gewicht inkl. Akku</th><td>0,8 kg (1.76 lb.)</td></tr><tr><th>Abmessungen (L × B × H)</th><td>225 × 136 × 73 (8.9 × 5.4 × 2.9 in.)</td></tr><tr><th>Farbe</th><td>Black</td></tr><tr><th>Akku-Typ</th><td>Rechargeable Lithium-ion battery</td></tr><tr><th>Akku-Spannung</th><td>3,65 V</td></tr><tr><th>Akku-Laufzeit</th><td>4 hours at +25°C (+77°F) ambient temperature and typical use</td></tr><tr><th>Ladesystem</th><td>Battery is charged inside the camera or in specific charger.</td></tr><tr><th>Ladezeit</th><td>2 hours in charger. 4 hours to 90% capacity in camera.</td></tr><tr><th>Energiemanagement</th><td>Automatic shut-down</td></tr><tr><th>Netzbetrieb</th><td>Recommended at least 27W USB-PD power adapter with USB-C connector, such as FLIR T912548</td></tr></tbody></table>
