FLIR E86 14° Wärmebildkamera · 464 × 348 Pixel · 7.5–14 µm

<table class="ds-table"><caption>Imaging &amp; Optik</caption><tbody><tr><th>IR-Auflösung</th><td>464 × 348 Pixel</td></tr><tr><th>UltraMax (Super-Resolution)</th><td>Ja</td></tr><tr><th>NETD</th><td>&lt;50 mK @ +30°C (+86°F)</td></tr><tr><th>Sichtfeld</th><td>14° × 10°</td></tr><tr><th>Mindestfokusabstand</th><td>1.0 m (3.28 ft.)</td></tr><tr><th>Mindestfokusabstand mit MSX</th><td>1.0 m (3.28 ft.)</td></tr><tr><th>Brennweite</th><td>29 mm (1.41 in.)</td></tr><tr><th>Räumliche Auflösung (IFOV)</th><td>0.52 mrad/pixel</td></tr><tr><th>Verfügbare Zusatzobjektive</th><td>24° (AutoCal) 42° (AutoCal) Dual FOV 24°/14° (service calibration required) 80° (service calibration required)</td></tr><tr><th>Objektiverkennung</th><td>Automatic</td></tr><tr><th>Blendenzahl (F#)</th><td>1.5</td></tr><tr><th>Bildfrequenz</th><td>30 Hz</td></tr><tr><th>Fokus</th><td>Continuous LDM One-shot LDM One-shot contrast Manual</td></tr><tr><th>Field of view match</th><td>Ja</td></tr><tr><th>Digital zoom</th><td>1–4× continuous</td></tr><tr><th>Detektor &amp; Spektralbereich</th><td>Uncooled microbolometer/7.5–14 µm</td></tr><tr><th>Detektor-Pitch</th><td>17 µm</td></tr></tbody></table>

<table class="ds-table"><caption>Messung</caption><tbody><tr><th>Kameratemperaturbereich</th><td>–20 to 120°C (–4 to 248°F) 0 to 650°C (32 to 1202°F) 300 to 1500°C (572 to 2732°F)</td></tr><tr><th>Messbereich und Genauigkeit</th><td>Range –20 to 120°C (–4 to 248°F) : –20 to 100°C (–4 to 212°F) : ±2°C (±3.6°F) 100 to 120°C (212 to 248°F) : ±2% Range 0 to 650°C (32 to 1202°F) : 0 to 100°C (32 to 212°F) : ±2°C (±3.6°F) 100 to 650°C (212 to 1202°F) : ±2% Range 300 to 1500°C (572 to 2732°F) : ±2%</td></tr><tr><th>FLIR Inspection Route</th><td>Enabled in the camera</td></tr><tr><th>Spotmessung</th><td>3 in live mode</td></tr><tr><th>Messfläche</th><td>3 in live mode</td></tr><tr><th>Automatische Heiß-/Kalt-Erkennung</th><td>Auto-maximum/minimum markers within area</td></tr><tr><th>Messvoreinstellungen</th><td>Nein measurements Center spot Hot spot Cold spot User preset 1 User preset 2</td></tr><tr><th>Differenztemperatur</th><td>Ja</td></tr><tr><th>Referenztemperatur</th><td>Ja</td></tr><tr><th>Emissionsgrad-Korrektur</th><td>Ja: variable from 0.01 to 1.0 or selected from materials list</td></tr><tr><th>Messkorrekturen</th><td>Ja</td></tr><tr><th>Korrektur externer Optiken/Fenster</th><td>Ja</td></tr><tr><th>Farbalarm (Isotherme)</th><td>Above Below Interval Condensation (moisture/humidity/dewpoint) Insulation</td></tr><tr><th>Messfunktionsalarm</th><td>Audible/visual alarms (above/below) on any selected measurement function</td></tr><tr><th>Farbpaletten</th><td>Arctic White hot Black hot Iron Lava Rainbow Rainbow HC</td></tr><tr><th>Einstelloptionen</th><td>Local adaptation of units, language, date and time formats</td></tr><tr><th>Sprachen</th><td>21</td></tr><tr><th>Kamera-Softwareupdate</th><td>Using USB cable or SD card</td></tr></tbody></table>

<table class="ds-table"><caption>Display &amp; Bedienung</caption><tbody><tr><th>Auflösung</th><td>640 × 480 Pixel (VGA)</td></tr><tr><th>Oberflächenhelligkeit</th><td>400</td></tr><tr><th>Display-Größe</th><td>4 in.</td></tr><tr><th>Betrachtungswinkel</th><td>80°</td></tr><tr><th>Farbtiefe</th><td>24</td></tr><tr><th>Seitenverhältnis</th><td>4:3</td></tr><tr><th>Auto-Rotation</th><td>Ja</td></tr><tr><th>Touchscreen</th><td>Optically bonded PCAP</td></tr><tr><th>Display-Technologie</th><td>IPS</td></tr><tr><th>Schutzglas</th><td>Dragontrail®</td></tr><tr><th>Programmierbare Tasten</th><td>1</td></tr><tr><th>Sucher</th><td>Nein</td></tr><tr><th>Image adjustment</th><td>Automatic Automatic maximum Automatic minimum Manual</td></tr><tr><th>IR-Bild</th><td>Ja</td></tr><tr><th>Visuelles Bild</th><td>Ja</td></tr><tr><th>Thermal Fusion</th><td>Nein</td></tr><tr><th>MSX</th><td>Ja</td></tr><tr><th>Bild-in-Bild</th><td>Resizable and movable</td></tr><tr><th>Galerie</th><td>Ja</td></tr></tbody></table>

<table class="ds-table"><caption>Visuelle Kamera</caption><tbody><tr><th>Auflösung</th><td>5 MP with LED light</td></tr><tr><th>Fokus</th><td>Fixed</td></tr><tr><th>Sichtfeld</th><td>53° × 41°</td></tr><tr><th>Videoleuchte</th><td>Built-in LED light</td></tr><tr><th>Laser-Ausrichtung</th><td>Position is automatically displayed on the infrared image</td></tr><tr><th>Laser-Entfernungsmesser</th><td>Activated by a dedicated button</td></tr><tr><th>Laser</th><td>Class 2, 0.05–40 m (1.6–131 ft.) ±1% of measured distance</td></tr></tbody></table>

<table class="ds-table"><caption>Schnittstellen &amp; Speicherung</caption><tbody><tr><th>Speichermedien</th><td>Removable memory: SD card (8 GB) FLIR Ignite Cloud services (with Wi-Fi)</td></tr><tr><th>Zeitraffer-Bildspeicherung</th><td>10 seconds to 24 hours (infrared)</td></tr><tr><th>Fernsteuerung</th><td>Using USB cable or Wi-Fi</td></tr><tr><th>Bilddateiformat</th><td>Standard JPEG, measurement data included. Infrared-only mode</td></tr><tr><th>Sprachkommentar</th><td>60 seconds built-in microphone and speaker (and via Bluetooth) on still images and video</td></tr><tr><th>Textkommentar</th><td>Text from predefined list or soft keyboard on touchscreen</td></tr><tr><th>Visuelle Bildnotiz</th><td>Ja</td></tr><tr><th>Bildskizze</th><td>Ja: on infrared images only</td></tr><tr><th>Skizze</th><td>From touchscreen</td></tr><tr><th>METERLiNK</th><td>Wireless connection (Bluetooth) to: FLIR meters with METERLiNK</td></tr><tr><th>Kompass</th><td>Ja</td></tr><tr><th>Laser-Entfernungsmesser-Info</th><td>Ja</td></tr><tr><th>Flächenmessungs-Info</th><td>Ja</td></tr><tr><th>GPS</th><td>Ja: location data automatically added to every still image and the first frame in video from built-in GPS</td></tr><tr><th>Radiometrische IR-Videoaufzeichnung</th><td>RTRR (.csq)</td></tr><tr><th>Nicht-radiometrische IR-Videoaufzeichnung</th><td>H.264 to memory card</td></tr><tr><th>Visuelle Videoaufzeichnung</th><td>H.264 to memory card</td></tr><tr><th>Radiometrisches IR-Video-Streaming</th><td>Over UVC</td></tr><tr><th>Nicht-radiometrisches Video-Streaming</th><td>H.264 (AVC) over RTSP (Wi-Fi) MPEG4 over RTSP (Wi-Fi) MJPEG over UVC and RTSP (Wi-Fi)</td></tr><tr><th>Visuelles Video-Streaming</th><td>Ja</td></tr><tr><th>Schnittstellen</th><td>USB 2.0, Bluetooth, Wi-Fi, DisplayPort</td></tr><tr><th>METERLiNK/Bluetooth</th><td>Communication with headset and external sensors</td></tr><tr><th>WLAN</th><td>Peer to peer ( ad hoc ) or infrastructure (network)</td></tr><tr><th>Audio</th><td>Microphone and speaker for voice annotation of images</td></tr><tr><th>USB</th><td>USB Type-C: data transfer/video/power</td></tr><tr><th>USB-Standard</th><td>USB 2.0 High Speed</td></tr><tr><th>Videoausgang</th><td>DisplayPort</td></tr><tr><th>Videoanschluss</th><td>DisplayPort over USB Type-C</td></tr><tr><th>Cloud-Anbindung</th><td>FLIR Ignite Cloud services</td></tr><tr><th>Betriebsfrequenz</th><td>Bluetooth + EDR/LE: 2402–2480 MHz WLAN 2.4 GHz: 2412–2462 MHz WLAN 5 GHz: 5150–5350 MHz (DFS: only slave mode) Note that frequency band 5150–5350 MHz is for indoor use only, see national regulations.</td></tr><tr><th>HF-Ausgangsleistung (EIRP)</th><td>Bluetooth + EDR/LE: &lt; 10 dBm WLAN: &lt; 17 dBm</td></tr><tr><th>Antenne</th><td>Integrated PIFA antenna (gain: maximum 1.4 dBi)</td></tr></tbody></table>

<table class="ds-table"><caption>Umwelt &amp; Normen</caption><tbody><tr><th>Betriebstemperatur</th><td>–15 to +50°C (5–122°F)</td></tr><tr><th>Lagertemperatur</th><td>–40 to +70°C (–40 to +158°F)</td></tr><tr><th>Luftfeuchte</th><td>IEC 60068-2-30/24 hours/95% relative humidity 25–40°C (77–104°F)/two cycles</td></tr><tr><th>EMC</th><td>ETSI EN 301 489-1 (radio) ETSI EN 301 489-17 EN 61000-6-2 (immunity) EN 61000-6-3 (emission) FCC 47 CFR part 15 B, class B (emission)</td></tr><tr><th>Funkspektrum</th><td>ETSI EN 300 328 ETSI EN 301 893 FCC 47 CFR part 15 C FCC 47 CFR part 15 E</td></tr><tr><th>Schutzart</th><td>IP 54 (IEC 60529)</td></tr><tr><th>Stoßfestigkeit</th><td>25 g (IEC 60068-2-27)</td></tr><tr><th>Vibration</th><td>2 g (IEC 60068-2-6)</td></tr><tr><th>Fallhöhe</th><td>Designed for 2 m (6.6 ft.)</td></tr><tr><th>Sicherheits-Normen</th><td>Camera: IEC/EN 60950-1, IEC/EN 62368-1 Power supply: IEC/EN 62368-1 CSA/UL/KC/SAA/PSE 60950-1</td></tr><tr><th>Konformitätserklärung</th><td>See: https://support.flir.com/resources/DoC</td></tr></tbody></table>

<table class="ds-table"><caption>Mechanik &amp; Stromversorgung</caption><tbody><tr><th>Akku-Typ</th><td>Rechargeable Li-ion battery</td></tr><tr><th>Akkuspannung</th><td>3.6 V</td></tr><tr><th>Akku-Laufzeit</th><td>&gt; 2.5 hours at 25°C (68°F) and typical use</td></tr><tr><th>Ladesystem</th><td>In camera (AC adapter or 12 V from a vehicle) or two-bay charger</td></tr><tr><th>Ladezeit (Zweifach-Ladegerät)</th><td>2.5 hours to 90% capacity with charging status indicated by LEDs</td></tr><tr><th>Ladetemperatur</th><td>0°C to +‎45°C (+‎32°F to +‎113°F) ‎, except for the Korean market: +10°C to +‎45°C (+‎50°F to +‎113°F)‎</td></tr><tr><th>Externe Stromversorgung</th><td>AC adapter 90–260 V AC, 50/60 Hz, or 12 V from a vehicle (cable with standard plug—optional)</td></tr><tr><th>Energiemanagement</th><td>Automatic shut-down and sleep mode</td></tr><tr><th>Akku-Dokumente</th><td>For documents like MSDS and UN38.3 test reports/summaries, see: https://support.flir.com/resources/msds</td></tr><tr><th>Gewicht inkl. Akku</th><td>1 kg (2.2 lb.)</td></tr><tr><th>Abmessungen (L × B × H)</th><td>278.4 × 116.1 × 113.1 mm (11.0 × 4.6 × 4.4 in.)</td></tr><tr><th>Akku-Gewicht</th><td>140 g (4.9 oz.)</td></tr><tr><th>Akku-Abmessungen (L × B × H)</th><td>150 × 46 × 55 mm (5.9 × 1.8 × 2.2 in.)</td></tr><tr><th>Stativ-Gewinde</th><td>UNC ¼″-20</td></tr><tr><th>Gehäuse-Material</th><td>PCABS with TPE, magnesium</td></tr><tr><th>Farbe</th><td>Black</td></tr></tbody></table>
